|Main Port:||Tianjin And Other Port In China||Grooving Type:||LBS-groove Or HELICAL-groove|
|Product Condition:||Fully Machined||Sling Type:||Wire Rope Or Cable|
|Application Area:||Drilling Operations, Crane, Hoisting, Offshore, Mine||Color:||According To Customer Demand|
|Rotation Direction:||Left Or Right|
wire rope drum,
anchor winch drum
High Strength Steel Integral Type Wire Rope Winch Drum For Crane Winch
carbon steel, all kinds of high-strength steel Q345, Q420, Q460, 15CrMo, 20GrMo, 42GrMo, etc
CNC machining center
1. Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
2. The petroleum industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , Logging winch, etc
3. Crane machinery: The bridge lifting machine, Tower crane, Gantry crane,Crawler crane winch
4. The construction machinery: Building wipe wall winch, Winding hoist, Windlass
5. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
6. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc
LBS grooved drum, solved the problem of bitten rope in wire rope winding process. LBS groove
system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology
greatly prolong the service life of wire rope, extend the service life of wire rope can be more than 500%,
reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem
of mechanical equipment shutdown for changing rope.
Integral rope groove drum: rope drums with grooves cut directly into them (with or without bolted or welded flanges, as required).Winch drum with flange, the LBS groove is cut directly into the body of the drum, according to customers’ requirements, the flanges are either welded or screw-bolted. groove geometry is determined by rope construction, diameter and length, and by application. the drum has the required mounting dimensions for the actual operating conditions.
|No:||Wire diameter(mm):||Rotation direction||Main drum
|Main drum length(mm)||Application|
|1||8 10 13||Lefthand,Righthand||430||763||The oil workover rig winch,
|2||13 18 20||Lefthand,Righthand||623||1144||Engineering winch,
Lifting winch,Crawler crane
|3||22 25 26||Lefthand,Righthand||730||1220||Oil workover rig ,
|4||18 22 32||Lefthand,Righthand||670||1240||Drilling Rig Winch, drawworks|
|5||28 32 36 40||Lefthand,Righthand||560||630||Rotating Drilling Rig winch,
|6||26 28 32 45||Lefthand,Righthand||760 1146||1970 1765||
Q1:What's your terms of payment?
A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.
Q2:What's your terms of delivery?
A. EXW, FOB CIF CFR etc
Q3:How about your delivery time?
A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.
Q4:Can you produce according to the samples?
A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.
Q5: What's your sample policy?
A. We can supply sample, but the customer have to pay the sample cost and courier cost.
Q6: Do you test all your goods before delivery?
A. Yes, we have 100% test before delivery.
