Customized High Power Hydraulic Tugger Winch LBS Grooves

Customized High Power Hydraulic Tugger Winch LBS Grooves
Customized High Power Hydraulic Tugger Winch LBS Grooves Customized High Power Hydraulic Tugger Winch LBS Grooves Customized High Power Hydraulic Tugger Winch LBS Grooves Customized High Power Hydraulic Tugger Winch LBS Grooves Customized High Power Hydraulic Tugger Winch LBS Grooves

Large Image :  Customized High Power Hydraulic Tugger Winch LBS Grooves

Product Details:
Place of Origin: Hebei,China
Brand Name: LBS
Certification: DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Model Number: Custom design
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 to 40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 500 Pieces/Sets Per Month
Detailed Product Description
Main Port: Tianjin China Power Source: Hydraulic
Rope Speed: 0-200m/min Grooving Type: LBS Grooves
Product Condition: Fully Machined Capacity: 500 - 6000kgs
Usage: Boat And Offshore Certification:: BV ABS DNV Etc
High Light:

hydraulic hoist and winch


hydraulic cable winch


Product structure:
Product name:hydraulic winch
other name :hydraulic boat winch or anchor winch
Rope speed :0~200 m/min
Groove type :LBS groove drum or as requirement
packing :wooden case
Parameter:can be design as requirment

Techinal parameter: can be design as customer


Model Rated load
Rated Speed
Rope Capacity(m) Rope Dia(mm) Motor Power (kw) Dimension(mm) Weight(KG)
JK0.5 5 22 190 7.7 Y100L-4 3 620*701*417 200
JK1 10 22 100 9.3 Y112M-4 4 620*701*417 300
JZ1.6 16 24 150 12.5 G132S-4 5.5 945*996*570 500
JZ2 20 24 150 13 G132M-4 7.5 945*996*570 550
JZ3.2 32 25 290 15.5 G180L-6 15 1325*1335*840 1011
JZ3.2B 32 30 250 15.5 JZ200L-6 22 1900*1738*985 1500
JZ5 50 30 300 21.5 JZ225M-6 30 1900*1620*985 2050
JZ5B 50 25 210 21.5 LBSM-8 22 2250*2500*1300 2264
JZ8 80 25 160 26 LBS280S-8 45 1533*1985*1045 3000
JZ10 100 30 300 30 LBS315S-8 55 2250*2500*1300 5100


Our design feature:LBS double grooved winch drum advantage:

  1. Each one circle layer of the grooved drum has two parallel groove and two groove section
  2. Make the cable even smooth ;load even distribution
  3. Prevent cross &mess in cable rolling working happening
  4. Lower the cable damage, extend the cable life
product composition:Hydraulic winch is made up of hydraulic motor, multi-disc friction brake, planet        gearbox, spool and bracket as a whole. There are shuttle valve and counter               balance valve keep the load from dropping, and maintain loading and unloading stable.and which can be optional according to customer needs.


Product application:
Winches are widely applied in track and shipping crane, gravity crushing traction equipment, pipe hoist machine, grab bucket and the drilling machine that has crushing function.


1) Planetary gearbox, smooth operation and reasonable structure.
2) Long life Danfoss hydraulic orbit motor
3Normally closed friction type brake, high braking torque, safe and reliable operating.
4) Balance valve, shuttle valve, limit switch and other accessories are also available on request
5) Low noise operation.


Our service:
1. We provide high quality, competitive price and worry free aftersales service.
2. We can design according to customers different technical specifications
3. One Year Quality Assurance
4. Free Components for replacement within warranty period
5. Professional solution provider
6. Free techinical support at anytime


Customized High Power Hydraulic Tugger Winch LBS Grooves 0

Service tenet:

My company's customer service tenet is: "Clients are always the first.”

Service strategy:

1. Information Service System

2. Professional service skills

3. Experienced after-sales team

Service content:

A: Pre-sales Service

1. Provide technical advisory services to assist customer in selection;
2. Provide customers with the necessary technical information, drawings, etc;

B: Sales Service

1. According to the relevant technical parameters, design drawings, or to provide customers with drawings of professional review, to provide the best solution and drawings.

2. Answers questions about specifications, performance, parameters, etc, and recommend the most appropriate solution.

3. Immediately after signing the contract, we make production planning for timely delivery.

C: After-sales Service

1. Provide technical advice during installation process;

2. In warranty period, if a quality-related problem occurs in normal use, please send a written description of the problem to us. We will respond within 24-48 hours.

3. Even if the warranty has expired, we are still glad to solve problems that are not due to improper use for you. All repairs will be billed at cost, and for long term, we supply spare parts at favorable price.



Q1:What's your terms of payment?

A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.

Q2:What's your terms of delivery?



Q3:How about your delivery time?

A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.

Q4:Can you produce according to the samples?

A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.


Q5: What's your sample policy?

A. We can supply sample, but the customer have to pay the sample cost and courier cost.


Q6: Do you test all your goods before delivery?

A. Yes, we have 100% test before delivery.
