Product structure:
Product name:hydraulic marinewinch
other name :hydraulic boat winch or anchor winch
Rope speed :0~200 m/min
Capacity:500~6000KGS
Groove type :LBS groove drum or as requirement
packing :wooden case
Power:hydraulic
Parameter:can be design as requirment
Techinal parameter: can be design as customer
| Model |
Rated load
(KN) |
Rated Speed
(m/min) |
Rope Capacity(m) |
Rope Dia(mm) |
Motor |
Power (kw) |
Dimension(mm) |
Weight(KG) |
| JK0.5 |
5 |
22 |
190 |
7.7 |
Y100L-4 |
3 |
620*701*417 |
200 |
| JK1 |
10 |
22 |
100 |
9.3 |
Y112M-4 |
4 |
620*701*417 |
300 |
| JZ1.6 |
16 |
24 |
150 |
12.5 |
G132S-4 |
5.5 |
945*996*570 |
500 |
| JZ2 |
20 |
24 |
150 |
13 |
G132M-4 |
7.5 |
945*996*570 |
550 |
| JZ3.2 |
32 |
25 |
290 |
15.5 |
G180L-6 |
15 |
1325*1335*840 |
1011 |
| JZ3.2B |
32 |
30 |
250 |
15.5 |
JZ200L-6 |
22 |
1900*1738*985 |
1500 |
| JZ5 |
50 |
30 |
300 |
21.5 |
JZ225M-6 |
30 |
1900*1620*985 |
2050 |
| JZ5B |
50 |
25 |
210 |
21.5 |
LBSM-8 |
22 |
2250*2500*1300 |
2264 |
| JZ8 |
80 |
25 |
160 |
26 |
LBS280S-8 |
45 |
1533*1985*1045 |
3000 |
| JZ10 |
100 |
30 |
300 |
30 |
LBS315S-8 |
55 |
2250*2500*1300 |
5100 |
Our design feature:LBS double grooved winch drum advantage:
- Each one circle layer of the grooved drum has two parallel groove and two groove section
- Make the cable even smooth ;load even distribution
- Prevent cross &mess in cable rolling working happening
- Lower the cable damage, extend the cable life
product composition:Hydraulic winch is made up of hydraulic motor, multi-disc friction brake, planet gearbox, spool and bracket as a whole. There are shuttle valve and counter balance valve keep the load from dropping, and maintain loading and unloading stable.and which can be optional according to customer needs.
Product application:
Winches are widely applied in track and shipping crane, gravity crushing traction equipment, pipe hoist machine, grab bucket and the drilling machine that has crushing function.
Feature:
1) Planetary gearbox, smooth operation and reasonable structure.
2) Long life Danfoss hydraulic orbit motor
3) Normally closed friction type brake, high braking torque, safe and reliable operating.
4) Balance valve, shuttle valve, limit switch and other accessories are also available on request
5) Low noise operation.
Our service:
1. We provide high quality, competitive price and worry free aftersales service.
2. We can design according to customers different technical specifications
3. One Year Quality Assurance
4. Free Components for replacement within warranty period
5. Professional solution provider
6. Free techinical support at anytime
FAQ:
|
Q1:What's your terms of payment?
A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.
|
|
Q2:What's your terms of delivery?
A. EXW, FOB CIF CFR etc
|
|
Q3:How about your delivery time?
A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.
|
|
Q4:Can you produce according to the samples?
A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.
|
|
Q5: What's your sample policy?
A. We can supply sample, but the customer have to pay the sample cost and courier cost.
|
|
Q6: Do you test all your goods before delivery?
A. Yes, we have 100% test before delivery.
|
