|Material:||High Strength Steel||Color:||Gray Or Other|
|Function:||Protect Drum||Grooving Type:||LBS Grooving Or Helical Grooving|
|Surface Hardness:||As Your Requirement||Rotation Direction:||Left Or Right|
|Width Between The Flanges:||According To The Drum Parameter|
winch spooling device,
wire rope spooling device
Title:Free customization the complete LBS drum and LBS split sleeve suit your drum
We also supply LBS grooved drum used in all kinds of winchs. The whole drum details as follows:
1. the groove is cut directly into the body of drum.
2. according to the customer' requirements, the flanges are either welded or screw-bolted.
3. the groove is available as either LBS-groove or helical-groove.
4. groove geometry is determined by rope construction, diameter and length ,and by application.
5. the drum is provided with the requested mounting dimensions to fit the flanges by welding or screw bolting.
Sleeves are used to prevent damage to a drum. It is usually cheaper to replace a worn out sleeve in stead of replacing or repair the complete drum assembly.
The LBS split-sleeve system consists of a pair of outer shells that are bolted or welded onto a smooth drum to provide a grooving pattern. either LBS parallel grooves can be carved into sleeves. As with all LBS drums, the grooving in split sleeves is engineer to suit much the specific rope construction, diameter and length.
We can design the LBS sleeve according to the drum's size and parameter.So the customer need to provide some paramter as follows:
|the drum's outer diameter||LBS sleeves diameter|
|width between the flanges||320mm 550mm or as your requirement|
|the rotation direction||left or right|
|wire rope diameter and structure||22mm 33mm or any others|
|the material||Q345B or high strength steel|
|the surface hardness||as your requirements
Q1:What's your terms of payment?
A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.
Q2:What's your terms of delivery?
A. EXW, FOB CIF CFR etc
Q3:How about your delivery time?
A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.
Q4:Can you produce according to the samples?
A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.
Q5: What's your sample policy?
A. We can supply sample, but the customer have to pay the sample cost and courier cost.
Q6: Do you test all your goods before delivery?
A. Yes, we have 100% test before delivery.
