China Shijiazhuang Jun Zhong Machinery Manufacturing Co., Ltd certification

The equipment trades completed in March, the winch wire rope drum has been installed, wire rope neatly arranged, the equipment is in good condition.

—— Zhang Zhipeng Singapore

Reliable quality, economic price, enthusiastic service, a pleasant cooperation

—— Earlina Adamson

The company has a very mature technology, product quality is impeccable, the details of the deal well, look forward to the next cooperation.

—— liu mingxiang

A very successful cooperation,the goods’ quality is reliable, while the after-service is timely.

—— Sandy Li

I'm Online Chat Now

Electric Hydraulic Anchor Windlass And Mooring Winch Wire Rope Sling Type

Large Image : Electric Hydraulic Anchor Windlass And Mooring Winch Wire Rope Sling Type

Product Details:

Place of Origin:	Hebei，China
Brand Name:	LBS
Certification:	DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Model Number:	LBSH / LBSJ

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export standard wooden case
Delivery Time:	30 to 40 working days, depends on order amount and specification
Payment Terms:	L/C, T/T
Supply Ability:	500 Pieces/Sets Per Month

Contact Now

Detailed Product Description

Main Port:	Tianjin China	Power Source:	Electric
Drum Type:	Smooth Drum With LBS Sleeves	Sling Type:	Wire Rope
Application:	Oil, Marine And Geological Exploration	Product Color:	According To Customer Demand
Highlight:	windlass boat winch , hydraulic towing winch

Brief view :
Product name: windlass winch
Durm type :smooth
Sling type:wire
Power:electric
Application:Oil, Marine And Geological Exploration
Function:pulling,pushing ,lifting ,hoisting ,fixed
Feature:low noise

Parts of model as follow:can design as customer

Name	Shipyard Windlass Winch
Maximum Reel Weight:	Approx 65Ton
Reel speed:	Approx 1-6 rpm
Maximum Reel Width:	2.27m
Minimum Reel Windth:	1.17m
Maximum Reel Diameter:	3.0m (Flange Diameter)
Overall Dimensions of machine:	L4.68m x W2.3m x H3.2m
Pedestal Dimensions:	L4.83m x W2.5m
Tension (back force) on cable:	Approx 100KN
Tension (back force) on cable at 1st layer:	Approx 50KN

Drum type:
The split-sleeve consists of a pair of outer shells that are bolted or welded onto the smooth drum of the windlass winch.

Shipyard Windlass Winch

1. Single or Multi-drum Type
4. Certificate Approval: ABS BV CCS DNV GL LR KR NK RINA RS etc.
5. With drag brake system
6. Configuration: horizontal arrangement
7. Rope speed: complying with ISO requirements

Product Material:
Carbon steel, alloy steel, cast steel, aluminum, all kinds of high-strength steel Q345, Q420, Q460, 15CrMo,20GrMo, 42GrMo, etc
Material standards: GB, AISI, ASME, ASTM, JIS DIN, NF, BS, EN ...
Classification societies certified: DNV, ABS, GL, LR, BV, CCS, RINA, NK, KR ...

Product features
1. Top quality with competitive price.
2. Compact structure and reasonable design
3. Safe and reliable function.
4. Highly efficient, constant operating torque motor.
5. Smooth running over the entire speed range.
6. Reliable operation with little noise.

Our services

1. One Year Quality Assurance
2. Free Components for replacement within warranty period
3. Professional solution provider
4. Free techinical support at anytime

5. Marine winch,electric anchor winch, hand winch ,hydraulic winches ,windlass,capstan and outfitting can be designed
FAQ:

Q1:What's your terms of payment?
A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.

Q2:What's your terms of delivery?
A. EXW, FOB CIF CFR etc

Q3:How about your delivery time?
A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.

Q4:Can you produce according to the samples?
A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.

Q5: What's your sample policy?
A. We can supply sample, but the customer have to pay the sample cost and courier cost.

Q6: Do you test all your goods before delivery?
A. Yes, we have 100% test before delivery.
