LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting

LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting
LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting

Large Image :  LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting

Product Details:
Place of Origin: SHIJIAZHUANG CITY
Brand Name: LBS
Certification: ISO BV
Model Number: LBSW
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 2000-10000/ Set
Packaging Details: Export standard wooden case
Delivery Time: 10-15 work days
Payment Terms: T/T, Western Union, MoneyGram
Supply Ability: 250 sets per month
Detailed Product Description
Material: High Strength Steel Load: 30T
Application: Ship Mine Construction Tower Rope Speed: 1.4m/s
First Layer Pull Force: 25KN Rope Capacity: 400m
Weight: 1.2 T Drum Size:: Customized
Highlight:

winch spooling device

,

wire rope spooling device

Title:LBS Brand Mining Dispatching Winch / Anchor Windlass for Construction Lifting




Product brief information:

Dispatching winch includes drum,brake device,motor,planetary gear transmission and frame.

Rotation Direction: Left or Right(as require)

Wire Rope Diameter: 3 MM~190 MM

Ropr capacity:100-10000M

Processing equipment: CNC machining center

Durm Type: LBS spooling system - based on the unique geometry of the drum groovingWinch

winch weight:1200kg

winch size: 1435x1217x1242 mm


Dispactching winch is mainly composed of drum and planetary gear transmission device,brake device,motor and base. The reduction mechanism of the winch adopts two sets of internal gear transmission pairs and a set of planetary gear system, two sets of internal gear pairs are installed in the drum body, the shaft end of the motor is equipped with casing gear directly into the drum,and rolling bearings are used in each rotation of the winch.

Name: dispatching winch wire rope tension: 30kn
drum diameter: 310mm drum length: 400mm
rope speed: 1.4m/s motor model: YBJ25-4



Product Application:

1. Crane machinery: The bridge lifting machine, Tower crane, Gantry crane,Crawler crane winch
2. The petroleum industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , Logging winch, etc
3. Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
4. The construction machinery: Building wipe wall winch, Winding hoist, Windlass
5. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
6. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc



Product Material:

Carbon steel, alloy steel, cast steel, aluminum, all kinds of high-strength steel Q345, Q420, Q460, 15CrMo,20GrMo, 42GrMo, etc

Material standards: GB, AISI, ASME, ASTM, JIS DIN, NF, BS, EN ...

Classification societies certified: DNV, ABS, GL, LR, BV, CCS, RINA, NK, KR ...



LBS Products Drum Feature:

  • Compact structure and reasonable design
  • Safe and reliable function
  • Highly efficient, constant operating torque motor.
  • Smooth running over the entire speed range.

LBS Mining Dispatching Winch Spooling Device Winch For Construction Lifting 0

Package and delivery:

packed by standard wooden case

It takes about 20 work days to arrange production.

FAQ:

Q1:What's your terms of payment?

A. T/T 50% deposit and 50% before delivery. we will show you the photos of products and packages before your pay the balance.

Q2:What's your terms of delivery?

A. EXW, FOB CIF CFR etc



Q3:How about your delivery time?

A. Generally,it will take about 10-30 days after receive your advance payment.The specfit delivery time depends on your order.quantitty.

Q4:Can you produce according to the samples?

A. Yes, we can produce by your sample and technical drawings, we can build mold and fixtures.



Q5: What's your sample policy?

A. We can supply sample, but the customer have to pay the sample cost and courier cost.



Q6: Do you test all your goods before delivery?

A. Yes, we have 100% test before delivery.
