Product Details:
Payment & Shipping Terms:
|
| Name: | 50 Ton Hydraulic Winch | Drum Quantity: | Single Or Double |
|---|---|---|---|
| Drum Design: | LBS Groove Or Spiral Groove | Material: | Carbon Stainless And Alloy Steels |
| Size: | Customization | OEM/ODM: | Yes |
| Power Source: | Hydraulic | Capacity: | 500kn |
| High Light: | hydraulic hoist and winch,hydraulic cable winch |
||
Title:50ton Hydraulic Winch with Signle or Double Drum for Marine Cargo Ship Boat Vessel
Product description:
Our 50 ton hydraulic winch is used for marine cargo ship boat vessel. It mainly includes 5 parts as follows:
1. Drive: hydraulic
2. Winch drum: single drum or double drum-----single layer spooling or multilayer spooling
3. Rated pull force(first layer):1--50 ton
4. Rope Speed:5-12m/min
5. Brake belt
Customization need more product technical parameters.
Drum features:
1. unique LBS groove--benifical for multilayer spooling
2. highly efficient and constant operating torque motor.
3. safe and reliable function
4. reasonable design and compact structure.
Techinical parameters:
| Name | First layer pull force (kn) | Drum size | Groove type |
| 30kn hydraulic winch | 30 | Φ300X450 | LBS |
| 50kn hydraulic winch | 50 | Φ350X500 | LBS or spiral |
| 60kn hydraulic winch | 60 | Φ400X600 | spiral or LBS |
| 70kn hydraulic winch | 70 | Φ600X680 | LBS or spiral |
| 80kn hydraulic winch | 80 | Φ750X700 | LBS or spiral |
| 100kn hydraulic winch | 100 | Φ800X1000 | LBS or |
