High Strength Steel Hydraulic Spooling Device Winch with 500 - 10,000m Cable Capacity for Drum Protection

High Strength Steel Hydraulic Spooling Device Winch with 500 - 10,000m Cable Capacity for Drum Protection
High Strength Steel Hydraulic Spooling Device Winch with 500 - 10,000m Cable Capacity for Drum Protection

Large Image :  High Strength Steel Hydraulic Spooling Device Winch with 500 - 10,000m Cable Capacity for Drum Protection

Product Details:
Place of Origin: Hebei，China.
Brand Name: LBS
Certification: ISO9000
Model Number: LBS-S
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 300-3000/ set
Packaging Details: export wooden box
Delivery Time: about 7-10 days
Payment Terms: T/T,Western Union
Supply Ability: 230 sets per month
Contact Now
Detailed Product Description
Product Name: Spooling Device Winch Cable Capacity: 500 - 10,000meter
Material: High Strength Steel Color: Gray Or Other
Function: Protect Drum Grooving Type: LBS Grooving Or Helical Grooving
Surface Hardness: As Your Requirement Rotation Direction: Left Or Right
Highlight:

hydraulic spooling device winch

,

high strength steel winch

,

drum protection winch

High Strength Steel Spooling Device Winch Hydraulic For Protect Drum
The Spooling Device Winch is specialized equipment engineered for precise and orderly winding and unwinding of steel wire ropes or cables. Its advanced design incorporates a precision winding mechanism, commonly referred to as a "coiler" or "cable guide" system.
Unlike conventional winches that simply stack cables on a drum, this hydraulic spooling device utilizes a laterally movable cable guide to systematically arrange cables layer by layer. This ensures tight, parallel winding on the drum during both winding and releasing operations, preventing premature wear, jamming, or damage caused by tangled, squeezed, or pinched cables.
Technical Specifications
Parameter Category Parameter Name Typical Specification/Range Unit Remarks
Core Performance Parameters Rated Pull Force 10 - 1,000 T Designed safe working load; core indicator
Core Performance Parameters Rope Capacity 500 - 10,000+ m Maximum rope length under matching diameter
Core Performance Parameters Rope Diameter 16 - 120+ mm Applicable rope range
Core Performance Parameters Max Line Speed 0 - 50 (adjustable) m/min Maximum value for empty rope or light load
Core Performance Parameters Designed Working Depth 1,000 - 6,000+ m Matches rope length and wire rope
Mechanical Structure Parameters Drum Flange Diameter 1,000 - 6,000+ mm Main dimension determining capacity
Mechanical Structure Parameters Drum Width 1,000 - 3,000+ mm
Mechanical Structure Parameters Rope Arranger Type Hydraulic/Servo Motor - Core mechanism to ensure neat rope arrangement
Safety Systems Main Braking System Hydraulic Disc Safety Brake - Fail-safe type; can lock automatically
Safety Systems Auxiliary Braking Energy Consumption/Mechanical Ratchet - For emergency situations or long-term holding
Power & Control Drive Mode Hydraulic Drive/Inverter Motor Drive - Depends on on-site power source and precision requirements
Power & Control Control Mode Local Control/Remote Control - Integrated into overall control system
Power & Control Tension Adjustment Mode Constant Tension/Programmable - High-precision; automatic adjustment
General Specifications Protection Grade IP56 / IP67 / IP68 - Dustproof and waterproof grade; suitable for deck environments
General Specifications Operating Ambient Temperature -20 ~ +50 °C Can be customized according to usage location
General Specifications Design Standards DNV-GL, ABS, API, etc. - Rope certification required per industry requirements
Key Options Integrated Measurement System Tension Sensor + Encoder - Real-time monitoring of rope length
Key Options Automatic Lubrication System Grease Lubricator - Optional; extends rope service life
Key Options Rope Tensioner Independent Rope Guide System - Ensures rope enters drum at optimal angle
Our Service Commitment
  • Customer-first approach with customized production tailored to client requirements and market-driven product upgrades
  • Comprehensive quality assurance through dedicated quality control departments and strict manufacturing standards
  • Complete after-sales service system including 24-hour response time and turn-key project services
  • Professional support for installation, debugging, maintenance, and technical assistance
Frequently Asked Questions
What are your payment terms?
T/T 50% deposit and 50% before delivery. We provide product and packaging photos before final payment.
What are your delivery terms?
EXW, FOB, CIF, CFR and other international trade terms available.
What is your typical delivery time?
Generally 10-30 days after receiving advance payment. Specific timing depends on order quantity and complexity.
Can you produce according to samples?
Yes, we can manufacture based on your samples and technical drawings, including building molds and fixtures.
What is your sample policy?
Samples are available with customer covering sample costs and courier charges.
Do you test all goods before delivery?
Yes, we perform 100% testing on all products before shipment to ensure quality and performance.
