Product Details:
Payment & Shipping Terms:
|
| Port: | Tianjin China | Used: | Drag/trailer Parts |
|---|---|---|---|
| Imposed Load: | 20T-100T | Product Color: | Black, Red, Brown Or Customized |
| Size: | 50mm(2 Inch)/ 90mm(3.5 Inch) | Mounting Height: | 150 |
| High Light: | semi truck fifth wheel,fifth wheel plate |
||
Casting Series Fifth Wheel type:
| Model Number |
Mounting Height (mm) |
Mounting Width (mm) |
Vertical load (T) |
D-value (KN) |
Weight (Kg) |
King pin size (mm) |
Function |
Capacity (T) |
| LBSCD50x - 15 | 150 | 800 | 15 | 120 | 110 |
Φ50 ( 2“) |
One-way | ＜30 |
| LBSCD50x - 18 | 185 | |||||||
| LBSCD50 - 15 | 150 | 900 | 20 | 152 | 135 | ≤50 | ||
| LBSCD50 - 18 | 185 | |||||||
| LBSCD50 - 25 | 250 | 145 | ||||||
| LBSCL50 - 29 | 290 | 165 | Two-way | |||||
| LBSCD90 - 18 | 185 | 960 | 36 | 260 | 190 |
Φ90 ( 3.5“) |
One-way |
＞50 ＜100 |
| LBSCD90 - 25 | 250 | 200 | ||||||
| LBSCL90 - 29 | 290 | 260 | Two-way |
Punching Series Fifth Wheel
| Model Number | material |
Thickness (mm) |
Mounting Height (mm) |
Mounting Width (mm) |
Vertical load (T) |
D-value (KN) |
Capacity (T) |
| LBSD90 | 16Mn | 12 | 185 | 960 | 51 | 424 | ≤100 |
| LBSD50 | 16Mn | 8 | 185 | 900 | 25 | 235 | ≤50 |
