Oil Drilling Equipment Offshore Winch Tractor Hoist Winch / Well Servicing Unit Winch
Overview
Quick Details
Product name :offshore winch ,windlass,marine winch
Place of Origin:Shijiazhuang, China (Mainland)
Brand Name:LBS
Model Number:OFLBS
Power Source:Electric
Application:crane, mine, port ,shipyard,boat, offshore
Usage:hoist,pulling ,trawing,hoist
Capacity:10 KN ~ 650 KN
Paint:Red or other color
Power source:380V 50Hz 3phase or according to your demand
Working duty:M3-M5
Warranty:12 months
drum:LBS ,smooth face or rope groove
Packaging & Delivery:woodencase ,25~30days after payment
Specifications
1. wirerope electric winch
2. operated and installed easily
3. used convenient
4. with high lifting speed
5.LBS groove drum can make work even well than other type drum
Technical parameters :
| No: |
Rated load
(KN)
|
Rope diameter
(MM)
|
Rope capacity
(M)
|
Rated speed
(M/min)
|
Motor power
(KW)
|
| 1 |
200 |
30 |
500 |
7.5 |
55 |
| 2 |
250 |
32 |
550 |
7.5 |
75 |
| 3 |
400 |
36 |
600 |
7.5 |
90 |
| 4 |
500 |
52 |
700 |
7.5 |
110 |
| 5 |
650 |
54 |
750 |
5 |
110 |
| 6 |
800 |
58 |
1100 |
5 |
132 |
| 7 |
1200 |
64 |
1100 |
5 |
180 |
| 8 |
1400 |
70 |
1300 |
5 |
220 |
| 9 |
1600 |
82 |
1300 |
4 |
220 |
| 10 |
2000 |
90 |
1500 |
4 |
250 |
| 11 |
2500 |
102 |
1800 |
4 |
300 |
| 12 |
3000 |
110 |
1800 |
4 |
360
|
The parameter can be signed by customer requirement.
Features:
1. The rubber-tyred type workover rig is generally equipped with self backed derrick. It has fast running speed and high construction efficiency. It is suitable for the quick removal.
2. Double drum workover rig winch
3. Product adoption LBS grooved drum, LBS groove system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.
Company profile:
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.
Ours services:
1. After-sales service provided: engineers available to service machinery overseas
2. The warranty is one year
3. Top quality with competitive price.
Winch drum material:
Carbon steel, alloy steel, cast steel, aluminum, all kinds of high-strength steel Q345, Q420, Q460,15CrMo, 20GrMo, 42GrMo, etc
