Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum

Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum
Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum

Large Image :  Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum

Product Details:
Place of Origin: Hebei,China
Brand Name: LBS
Certification: DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Model Number: Custom design
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 to 40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 500 Pieces/Sets Per Month
Detailed Product Description
Port: Tianjin China Drum Type: LBS Groove
Power Source: Electric Or Hydraulic Wire Diameter: 3 MM~190 MM
Application: Narrow Working Space Product Condition: Fully Machined
High Light:

hydraulic anchor winch

,

oil winch

Brief view:



Specifications:
Custom-made ( according to customer requirements )
1.Name: Crawler crane winch
1. Compact structure, small volume, light weight.
2. Winch drum :LBS grooved
3. Advantage of the design: Lower noise,even load distribution,suitable for heavy working condition
4. Light weight, easy transport

Technical parameters :



No:

Rated load

(KN)

Rope diameter

(MM)

Rope capacity

(M)

Rated speed

(M/min)

Motor power

(KW)

1 200 30 500 7.5 55
2 250 32 550 7.5 75
3 400 36 600 7.5 90
4 500 52 700 7.5 110
5 650 54 750 5 110
6 800 58 1100 5 132
7 1200 64 1100 5 180
8 1400 70 1300 5 220
9 1600 82 1300 4 220
10 2000 90 1500 4 250
11 2500 102 1800 4 300
12 3000 110 1800 4

360


Our services:
1. Engineers available to service machinery overseas.
2. Our products have one year warranty.
3. Except for standard winches, we’re also able to provide tailored solutions to our customers.



Application:
The crawler crane can carry out material lifting, transportation, loading and unloading and installation. Crawler crane with a lifting capacity of strong, grounding than the small, small turning radius, climbing ability, without leg, belt driving load, operation stability and the advantages of truss composite height can be free replacement, in electric power, municipal, Bridges, petrochemical industry, water conservancy and hydropower construction industry such as widely used.



Features:
1. Adopt dual-line LBS Grooves so that the load is evenly distributed between the each layer,which greatly extend the use life of steel wire and also improve construction safety. LBS drum realizes a multi-layer winding of steel wire rope, greatly improving the service life of steel wire rope
2. Hydraulic system adopts advanced load-feedback technology.Realizing hydraulic liquidity allocate to different parts according to the operation demand. Top key parts guarantee high reliability,such as pump,motor,valve,pipe and joint come from internation top brands





Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum 0



Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum 1



Electric / Hydraulic Crawler Crane Winch Crane Windlass Groove Drum 2
