Product Details:
Payment & Shipping Terms:
|
Port: | Tianjin China | Sling Type: | Wire Rope |
---|---|---|---|
Grooving Type: | LBS Groove | Color: | As Per Your Specification |
Material: | Alloy Steel | Application: | Ship, Port, Hoisting Machinery Industry... |
Highlight: | lebus grooving,drum sleeve |
1) Wire rope diameter (mm)
2) The Main Drum diameter (mm)
3) The Main Drum length (mm)
4) Rope capacity
5) Drum material
6) Maximum operating load on rope or cable
7) Type of rope entry
8) Direction of wire rope entry
9) Distance to fixed sheave and position between flanges
10) Flange diameter
11) Drum drawing
LBS SPECIAL GROOVE DRUM WORKING CONDITIONS.doc
TECHNICAL PARAMETERS PROVIDED BY CUSTOMER.doc
1.LBS drum split sleeves can be placed over smooth and ungrooved drums – suitable for modification or replacement of drum.
2.Split-sleeve system consists of a pair of outer shells that are bolted or welded onto a smooth drum to provide a grooving pattern.
3.The split sleeve is composed of spiral groove and parallel groove.
4.The groove design conforms to the specified wire rope structure, diameter and length.
1. Marine machinery: offshore petroleum crane winch, drawworks and hoist
2. The petroleum industry: oil drilling rig, petroleum tractor hoist, petroleum workover rig, trailermounted pumping unit winch , etc
3. Engineering machinery: tower crane, piling machine
4. Crane machinery: the bridge lifting machine, tower crane
5. The hoist: building wipe wall machine, winding machine
......
No: | Wire diameter(mm): | Rotation direction | Main drum diameter(mm) |
Main drum length(mm) | Application |
1 | 8 10 13 | Lefthand,Righthand | 430 | 763 | The oil workover rig winch, Towing winch Tower crane |
2 | 13 18 20 | Lefthand,Righthand | 623 | 1144 | Engineering winch, Lifting winch,Crawler crane |
3 | 22 25 26 | Lefthand,Righthand | 730 | 1220 | Oil workover rig , Logging Winch |
4 | 18 22 32 | Lefthand,Righthand | 670 | 1240 | Drilling Rig Winch, drawworks |
5 | 28 32 36 40 | Lefthand,Righthand | 560 | 630 | Rotating Drilling Rig winch, Lifting equipment |
6 | 26 28 32 45 | Lefthand,Righthand | 760 1146 | 1970 1765 |
Offshore Crane, |
......
