Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan

Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan
Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan

Large Image :  Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan

Product Details:
Place of Origin: Hebei,China
Brand Name: LBS
Certification: DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Model Number: Custom design
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 20 to 30 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 1000 Pieces/Sets Per Month
Detailed Product Description
Main Port: Tianjin China Grooving Type: LBS Grooves
Sling Type: Steel Wire Rope Specifications: Custom Design Or Drawings
Application: Marine Oilfield Drill Rigs Color: According To Customer Demand
High Light:

rope winch drum

,

electric hoist winch

Alloy Steel LBS Grooved Drum For Oil Drilling Rig Drawworks




Technical parameters and application:



No:Wire diameter(mm):Rotation directionMain drum
diameter(mm)
Main drum length(mm)Application
18 10 13Lefthand,Righthand430763The oil workover rig winch,
Towing winch.Tower crane
213 18 20Lefthand,Righthand6231144Engineering winch,
Lifting winch,Crawler crane
322 25 26Lefthand,Righthand7301220Oil workover rig ,
Logging Winch
418 22 32Lefthand,Righthand6701240Drilling Rig Winch, drawworks
528 32 36 40Lefthand,Righthand560630Rotating Drilling Rig winch,
Lifting equipment
626 28 32 45Lefthand,Righthand760 11461970 1765

Offshore Crane,
Marine crane,Mooring winch



......


Product material:
Carbon steel, Stainless steel, Aluminum, Alloy steel, All kinds of high-strength steel Q345, Q420, Q460, 15CrMo, 20GrMo, 40GrMo, 42GrMo, etc
Material standards: GB, AISI, ASME, ASTM, JIS DIN, NF, BS, EN ...
Classification societies certified: DNV, ABS, GL, LR, BV, CCS, RINA, NK, KR ...


Product advantage:
LBS grooved drum, solved the problem of wire rope spooling.
Compared with ordinary cordless groove (smooth) drum and helical rope groove drum, LBS rope groove has obvious advantages in the multi-layer wire rope spooling, LBS special groove system makes the spooling of wire rope smooth, and the load of each layer evenly distributed, extend the service life of rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.



Product structure:
Integral wire rope groove drum: rope drums with grooves cut directly into them (with or without bolted or welded flanges, as required).Winch drum with flange, the LBS groove is cut directly into the body of the drum, according to customers’ requirements, the flanges are either welded or screw-bolted. groove geometry is determined by rope construction, diameter and length, and by application. the drum has the required mounting dimensions for the actual operating conditions.



Product application:
1. The construction machinery: Building wipe wall winch, Winding hoist, Windlass
2. Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
3. The petroleum industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , Logging winch, etc
4. Crane machinery: The bridge lifting machine, Tower crane, Gantry crane,Crawler crane winch
5. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
6. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc



Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan 0


Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan 1


Alloy Steel LBS Grooved Drum For Oil Drilling Rig Capstan 2
