Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life

Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life
Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life

Large Image :  Offshore Marine Platform Wire Rope Marine Drum Winch Long Service Life

Product Details:
Place of Origin: Hebei,China
Brand Name: LBS
Certification: DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: Negotiation
Packaging Details: Export standard wooden case
Delivery Time: 30 to 40 working days, depends on order amount and specification
Payment Terms: L/C, T/T
Supply Ability: 500 Pieces/Sets Per Month
Detailed Product Description
Port: Tianjin China Wire Diameter: 3 MM~190 MM
Rope Capacity: 100m~10000m Power Source: Electric Or Hydraulic
Application: Marine Winch , Oil Winch... Product Condition: Fully Machined
Highlight:

marine electric winch

,

marine anchor winch

Product brief :



Product name

offshore marine winch
othe name marine platform winch
Brand LBS
Rope Dia 3-199mm
Rope capacity 100-1000M
Power electric or hydraulic
parameter designed as requirement



Parameters

Items Parameters
Working Pressure Of Compressed Air(MPa) 0.8-1.0
Max. Pull Force (KN) 100
Max. Wire Rope Speed (m/min) 12



Piston Air Motor

Model TMH30
Rated Power (KW) 30
Air Consumption (L/s) 400



Drum

Diameter (mm) 300
Width= (mm) 620
Wheel Rim Diamete= (mm) 650
Rope Diameter(mm) 24
Rope Storage(m) 200
Air Inlet Diameter (inch) 1 1/2"
Brake Type Hand Brake and Auto Band Brake



Dimension



Length (mm) 1700
Width (mm) 1250
Height (mm) 1200



Product advantage for us :



If you using the snooth drum winch before for a sometime ,you will find that you want to chage the rope type or the capacity or some usage working function like that ,now you only want to buy a LBS groove sleeve installing on the smooth drum instead of to chage the whole winch .That is convinent and save the time and money for you .Do you get the tip?



Product specification

Custom-made (according to actual requirement)



Product applications

Our company specialized in design and produce various types of electric and hydraulic anchor windlass , mooring winch, luffing crane and boat plane and rack, winch, engineering winch, cable winch and towing winch(The main drum is used LBS grooved drum)



Ours services

1. After-sales Service Provided: Engineers available to service machinery overseas

2. The warranty is one year

3. Top quality with competitive price

4. The engineer can provide overseas service

5. Quick and responsible after-sales service



LBS groove drum advantage

LBS grooved drum, solved the problem of bitten rope in wire rope winding process. LBS groove
system makes the winding of wire rope smooth, and the load of each layer evenly distributed,the technology greatly prolong the service life of wire rope, reduce the wire rope damage, improves the safety of the operation of the equipment, and reduces the problem of mechanical equipment shutdown for changing rope.
