20 Ton 50 Ton Electric Wire Rope Winch Steel Cable Industrial Electric Winch

Large Image : 20 Ton 50 Ton Electric Wire Rope Winch Steel Cable Industrial Electric Winch

Product Details:

Place of Origin:	Hebei，China
Brand Name:	LBS
Certification:	DNV, ABS, GL, LR, BV, CCS, RINA, NK,

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export standard wooden case
Delivery Time:	30 to 40 working days, depends on order amount and specification
Payment Terms:	L/C, T/T
Supply Ability:	500 Pieces/Sets Per Month

Contact Now

Detailed Product Description

Main Port:	Tianjin China	Power Source:	Electric
Motor Power:	3~160KW	Rope Capacity:	100~3600m
Color:	As Your Demand	Application:	Cranes,lifting, Pulling, Hoisting
High Light:	electric hoist winch , electric power winch

Features:

1.Procut name:electric wire rope winch

2.power:electric or hydraulic

3.Motor power:3-160KW

4.Rope capacity:100-3600M

5.Drum design:LBS groove drum

6. Slow speed, Steadly working
7. Light duty, compact design, beauty and reasonable price
8. High strength component, Durable and Reliable

Parameter :can be design as application and working condition

Model	Frirst layer Pull force(T)		Drum bottom diameter	Layer	Rope capaticty(mm)	Diameter of steel cable(mm)	Model of power
LBSEOF3-10	1	7-12	305	4	170	15	EW2-420 D51
LBSEOF3-20	2	7-28	380	4	180	20	EW3-900 D240 101
LBSEOF3-30	3	6-25	470	4	240	24	EW5-1800 D240101
LBSEOF3-40	4	10-23	470	4	270	28	EW6-2000 D240 101
LBSE0F3-50	5	10-25	600	4	300	30	EW6-3000 D240101
LBSEOF3-10	10	15-30	640	10	700	40	EW7-4300 D240101

Electric Winch Brief introduction:

The winch is lifting equipment winding wire rope or chain lifting or pulling heavy loads with the reel, also called winch, because it is simple and convenient, large amount of rope winding displacement and widely used. Mainly used in construction, water conservancy projects, forestry, mines, docks and other material lifting or flat dragging.

1. Wire Rope

The wire rope meets the requirements of GB/T8918,
Its safety factor greater than 5.
The Security lap number of Wire rope retained on the drum should not less than three rounds. When Wire rope retained on the drum just two rounds, the wire rope can withstand 125% of rated load.

2. Drum

The drum diameter not less than 19 times of the wire rope diameter.
The drum wall can withstand the wrapped tight force of wire rope; the side can withstand the lateral force produced by wire rope.
The distance between drum side plate peripheral to the outermost roll rope not less than twice of the wire rope diameter.

3. Brake

The brake wheel generally use ZG270-500, when the brake wheel diameter less than 300mm, it can use HT200.When the clutch is in a relaxed state, the two joints should be completely separated.

4. Motor & Electrical system

The duty of the motor and quota in accordance with GB/T755 rules.

The protection grade motor, button, switch and other electrical device not lower than GB4942.1 and IP44 level specified in the T4942.2.

Electrical control equipment and component set in cabinet; electrical box has a door lock.

The electrical equipment installed firmly, electrical connection is good, not easy to loose, and in accordance with the provisions of GB50150.

20 Ton 50 Ton Electric Wire Rope Winch Steel Cable Industrial Electric Winch 0

20 Ton 50 Ton Electric Wire Rope Winch Steel Cable Industrial Electric Winch 1
