LBS Grooves Offshore Winch Oil Well Drilling Rig Parts Winch With Brake Disc

Large Image : LBS Grooves Offshore Winch Oil Well Drilling Rig Parts Winch With Brake Disc

Product Details:

Place of Origin:	Hebei，China
Brand Name:	LBS
Certification:	DNV, ABS, GL, LR, BV, CCS, RINA, NK,
Model Number:	Custom design

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export standard wooden case
Delivery Time:	30 to 40 working days, depends on order amount and specification
Payment Terms:	L/C, T/T
Supply Ability:	500 Pieces/Sets Per Month

Contact Now

Detailed Product Description

Port:	Tianjin	Grooving Type:	LBS Grooves
Brake:	Brake Disc	Sling:	Wire Rope
Color:	According To Customer Demand	Application:	Well Drilling Machinery
Model Number:	LBSM1-10	Capacity:	1~65 Ton
High Light:	hydraulic anchor winch , mine winches

Why you should choose us:

1)Own LBS groove patent by goverment

2)Have done most of successfully case in offshore, mining ,marine ,and crane areas

3)Can give more even speilized service to make the rope working ordely and tell your how to save time and cost for maintain service.

Product feature :

Product Name	hydraulic winch
Material	steel
Color	blue or customized
Standard	ISO
Brake	Hydraulic brake system
Brand	LBS
Origin Place	China
Used	hoist ,lifting,trawing ,pulling
Parameter	Can be design as customer requirement

Our brand LBS design advantage :

Each one circle layer of the grooved drum has two parallel groove and two groove section
Make the cable even smooth ;load even distribution
Prevent cross &mess in cable rolling working happening
Lower the cable damage, extend the cable life

Technical parameter

Model	Frirst layer Pull force(LN)	Rope speed(n/min)	Drum bottom diameter	Difference of working pressures(Mpa)	Rope capaticty(mm)	Diameter of steel cable(mm)	Model of power
LBSOF1-10	30	0-35	305	15.9	65	15	XH2-420 D51
LBSOF1-20	50	0-40	380	16.3	70	20	XH3-900 D240 101
LBSOF1-30	80	0-40	470	15.6	100	24	XH5-1800 D240101
LBSOF1-40	100	0-40	470	16	90	28	XH6-2000 D240 101
LBS0F1-50	120	0-30	600	17.3	175	30	XH6-3000 D240101
LBSOF1-60	150	0-30	640	17.8	143	38	XH7-4300 D240101
LBS OF1-70	200	0-25	660	17.8	150	40	XH8-900d240101

Useage:

Winch (drawworks) is widely used to deliver tools, hoist/descend derricks and run the drilling tools and pipe shrouds into the well during the drilling process.

Hydraulic disc brake:

Hydraulic disc brake with brake torque capacity, braking performance and stability, flexible operation, labor saving, convenient maintenance, safe and reliable, can improve the system performance, improve workover and drilling time. Hydraulic disc brake also has high control accuracy, easy remote operation, easy to realize automatic tripping and autodriller function, and low noise, suitable for the environment sensitive areas of work.

Mechanically driven winches:

At both the high and the low speed ends of the roller, a ventilated air tube clutch is installed. The rim of a brake (or a brake disc) is subject to forced cooling with circulating water and surface medium-frequency hardening, thus featuring satisfactory wear resistance and extended service life. The main brake is of hydraulic pad or band type, and the auxiliary adopts dynamic braking or EATON products (cooled by water or air). All gear shift clutches are provided with involutes and spline teeth and adopt cylinder or pneumatic tire clutch shift structure to ensure simple, easy and reliable stage changeover. In the roller is provided with a LBS rope groove so as to achieve automatic delivery of drilling tools.

Features:

1. Our products have the advantages of compact structure, light weight, safe and easy to operate.

2. Our products are used for general lifting, hauling and other works in marine deck machinery, harbor, petroleum, drill machine, engineering machinery, mining, geological exploration and construction machinery and etc.

3. Products are designed and manufactured according to API Spec 7K “Specification for Drilling Equipment”.

4. High starting& working efficiency

5. Reliable operation with little noise

Our services:

1. Engineers available to service machinery overseas.

2. Our products have one year warranty.

3. A range of accessories such as pressure rollers are available on request.

4. Except for standard winches, we’re also able to provide tailored solutions to our customers.

LBS Grooves Offshore Winch Oil Well Drilling Rig Parts Winch With Brake Disc 0

LBS Grooves Offshore Winch Oil Well Drilling Rig Parts Winch With Brake Disc 1

LBS Grooves Offshore Winch Oil Well Drilling Rig Parts Winch With Brake Disc 2
