Product brief view
| Product name |
Hydraulic LBS windlass |
| Other name |
offshore tower winch/anchore boat winch/towing winch |
| Drum design |
LBS drum |
| Rotation Direction |
left or right |
| Sling type |
wire or cable |
| Rope capactiy: |
20-2000mm |
| Rope diameter |
3-150mm |
| Parameter |
can be design as customer or function application |
| Colour |
as customer base |
Parameter :can be designed
| Model |
Layer plly force
(T)
|
Rope speed |
Drum bottom diameter |
Difference of working pressures(Mpa) |
Rope capaticty(mm) |
Diameter of steel cable(mm) |
Model of power |
| LBSHM1-10 |
30 |
0-35 |
305 |
15.9 |
65 |
15 |
JH2-420 D51 |
| LBSHM1-20 |
50 |
0-40 |
380 |
16.3 |
70 |
20 |
JH3-900 D240 101 |
| LBSHM1-30 |
80 |
0-40 |
470 |
15.6 |
100 |
24 |
JH5-1800 D240101 |
| LBSHM1-40 |
100 |
0-40 |
470 |
16 |
90 |
28 |
JH6-2000 D240 101 |
| LBSHM1-50 |
120 |
0-30 |
600 |
17.3 |
175 |
30 |
JH6-3000 D240101 |
| LBSHM1-60 |
170 |
0-30 |
650 |
18 |
145 |
38 |
JH7-4300 D240101 |
product features
1. Two-or three-stage planetary gearboxes, smooth operation and reasonable structure.
2. Normally closed friction type brake, high braking torque, safe and reliable operating.
3. Small volume, compact structure and high transmission efficiency.
4. Axial fixed or variable hydraulic motor with long life operating.
5. Mounting frame is available on request.
6. Balance valve, shuttle valve, limit switch and other accessories are also available on request.
Product specification
Custom-made (according to actual requirement)
Applications
1. Offshore Marine machinery: Offshore petroleum crane winch, Mooring winch, Traction winch, Man-riding winch, Anchor winch, Hydrologic winch
2. The petroleum industry: Oil drilling rig, Petroleum tractor hoist, Petroleum workover rig, Trailermounted pumping unit winch , oil Logging winch, etc
3. Crane machinery: Lifting machine, Tower crane machinery, Gantry crane,Crawler crane winch
4. The construction machinery: Building wipe wall winch, Winding hoist, Windlass
5. Engineering machinery: Cable winch, Tower crane, Piling machine, Hydraulic winch
6. Mining winch: Dispatching winch, Prop-pulling winch,Sinking winch, etc
Our Services
1. One Year Quality Assurance
2. Free Components for replacement within warranty period
3. Professional solution provider
4. Free techinical support at anytime
Company profile
Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories.
