Product Details:
Payment & Shipping Terms:
|
| Driven Type: | Electric Or Hydraulic | Material: | Carbon Steel |
|---|---|---|---|
| Specification: | As Per Request | Chain Diameter: | 10.5-120mm |
| Warping Load: | 5-350kn | ||
| High Light: | windlass boat winch,hydraulic towing winch |
||
Name:Quality Marine Electric Anchor Windlass Combined Mooring Winch for Sale
Product description:
Anchor Windlass is specially applied for boat or ship anchoring, and it is important anchor machine which helps boat or ship docking or setting sail safely and quickly and keeping the position of boat or ship and also used for ship emergency brake. Combined anchor windlass mooring winch is a device of marine equipment used for boat or ship anchoring (drop and hoist anchors) to holds a boat in place to a pier or similar fixture. The marine windlass/winch contains an anchor windlass and a winch drum around which sailors can wrap rope, chain, or cable.
Features:
| 1. | Perfect starting and working efficiency |
| 2. | LBS grooving drum for smoothly spooling |
| 3. | Easy and safe operation |
| 4. | Easy installation and low maintenance |
| 5. | Perfect erosion resistant coating |
| 6. | Reasonable compact structure design |
Product specification:
| driven type | hydraulic or electic |
| configuration | windlass brake /drum brake /hydraulic motor/operation mechanism of clutch etc |
| rated pull | 6kn-500kn |
| chain diameter | 12.5-100mm |
| working speed | low speed |
Quality Assurance and Service:
| 1. | Have complete rigorous management, production and inspection processes to control the quality and avoid detail mistake |
| 2. | Design and produce ability |
| 3. | Provide professional customization service according to client's requirements |
| 4. | Advanced manufacturing facility to ensure quality. |
| 5. | On time delivery as we have rigorous production schedule and profession follow-up process |
| 6. | Rigorous inspection including incoming inspection, flaw detection etc., double check is a must. |
| 7. | Response to any inquiry within 24 HRS with design or efficient solution from our engineer or tech supporter. |
| 8. | Response to any inquiry within 24 HRS with design or efficient solution from our engineer or tech supporter. |
Our company:
We design and research the LBS grooving on smooth drums. The LBS are made to solve the mess & cross problems in multilayer’ winding processing. Compared with cordless groove
drum and helical groove drum,LBS grooved drum has obvious advantages in multilayer spooling.One advantage is safety. And it can lower the rope damage, extend the rope life.
We are a professional supplier of marine windlass and winch, marine capstans, shark jaw/towing pin, marine crane, steering gear systems etc. We can customize ordinary or special marine windlass and winch for your application according to your drawings or requirement with good quality at competitive price.
