High Precision Double-Fold Lebus Grooved Winch Drum Q355D Tower Crane Winch Drum With Brake Disc Assembly

1.Product Description

This Lebus grooved winch drum assembly is manufactured from Q355D low-temperature impact resistant steel, specially engineered for multi-layer orderly wire rope spooling under heavy lifting conditions. It adopts double-fold Lebus rope grooves with 45° right-hand design, matched for Φ18 steel wire rope and supports up to 5 winding layers.
The complete assembly includes drum barrel, end plates, connection brackets, positioning pins and integrated brake disc. Strict welding process with post-weld stress relief eliminates welding deformation. Geometric tolerance and dimension tolerance follow GB/T1804-m and GB/T1184-k standards.
Surface treatment includes shot blasting, epoxy zinc-rich primer and polyurethane topcoat in RAL7031, total dry film thickness ≥100μm. The brake disc is machined to controlled roughness between Ra1.6~Ra3.2 for stable braking performance. It is built to withstand harsh offshore, marine and heavy crane working environments, preventing rope crossing, biting and disorderly winding, extending wire rope service life greatly.

2.Product Parameter

3.Product Advantage

1. Lebus double-fold groove design: Avoids rope crossover, eliminates rope biting and tangling during multi-layer winding, keeps neat spooling.
2. Q355D steel substrate: Excellent low-temperature toughness and impact resistance, suitable for cold offshore working sites.
3. Integrated brake disc assembly: Matched brake surface with controlled roughness guarantees reliable and stable braking.
4. Stress-relieved welded structure: Low welding deformation, high concentricity (runout tolerance 0.025mm referenced to datum A), stable rotation.
5. Heavy-duty anti-corrosion coating: Shot blasting + dual paint system, good salt spray resistance for marine & offshore service.
6. Precision machining: Strict tolerance control, interchangeable connecting components for easy installation and maintenance.

4.Product Application

This Lebus winch drum is widely used for offshore platform cranes, marine deck winches, port hoisting machinery, engineering hydraulic winches and heavy lifting equipment. It fits marine lifting, offshore oil & gas operation, dock cargo handling and other heavy-load hoisting scenarios where multi-layer orderly wire rope winding and reliable braking are required. It can be matched with hydraulic winch systems for continuous heavy-duty hoisting and pulling work.
