Electric 20 T Spooling Winch Hydraulic Electric Marine Mooring Winch

Large Image : Electric 20 T Spooling Winch Hydraulic Electric Marine Mooring Winch

Product Details:

Place of Origin:	Hebei，China
Brand Name:	LBS
Certification:	DNV, ABS, GL, LR, BV, CCS, RINA, NK,

Payment & Shipping Terms:

Minimum Order Quantity:	1 set
Price:	Negotiation
Packaging Details:	Export standard wooden case
Delivery Time:	30 to 40 working days, depends on order amount and specification
Payment Terms:	L/C, T/T
Supply Ability:	500 Pieces/Sets Per Month

Contact Now

Detailed Product Description

Main Port:	Tianjin China	Sling Type:	Steel Wire Rope
Drum Type:	Smooth Drum	Color:	According To Customer Demand
Specifications:	Custom Design Or Drawings	Product Condition:	Fully Machined
High Light:	windlass anchor winch , hydraulic towing winch

Product brief introduce:

1) Drive: Electric / hydraulic

2) Configuration: Single or double drum with / without warping end

3) Wire drum: Steel wire rope smooth drum or LBS grooved drum or LBS sleeves

4) Rated pull (1st layer): 10 to 2500KN

5) Brake: Hydraulic brake, mechanical brake

6) Paint: As per your specifications

7)Sling type:wire rope

Parts of model as follow

Model		LBS1	LBS3	LBS5	LBS8	LBS10
Line pull capacity (kg)		1000	3000	5000	8000	10000
Wire rope average speed (m/min)		30	30	28	20	19
Wire rope Dia.( mm):		9.3	15.5	21.5	26	30
Reduction box	Type	JZQ350	JZQ500	JZQ650	JZQ650	JZQ750
Reduction box	Transmission ratio	31.5	23.34	40.17	23.34	23.34
Drum (mm)	Diameter()	190	325	406	500	550
Drum (mm)	Length	360	520	840	900	1000
Capacity(m)		110	200	300	300	450
motor	Type	Y132M-4	YZR225M-8	YZR250M1-8	YZR250M1-6	YZR250M2-6
	Power(kW)	7.5	22	30	37	45
	Rotating speed(r/min)	1440	715	864	960	960
Hydraulic Brake		YWZ-200/25	YWZ-200/25	YWZ-300/45	YWZ-300/45	YWZ-400
Dimension (cm)		945x97x60	147x140x95	186x166x95	240x180x110	250x190x120
Weight(kg)		460	1200	2700	4000	5000

Company services

1. Our company specialized in design and produce various types of electric and hydraulic anchor windlass , mooring winch, luffing crane and boat plane and rack, winch, engineering winch, cable winch and towing winch(The main drum is used LBS grooved drum)

2. One year of warranty

3. The engineer can provide overseas service

4. Quick and responsible after-sales service

5. Very competitive price

Company profile

Our factory mainly in the service of hoisting machinery, Marine machinery, petroleum machinery, hydraulic machinery, engineering machinery and other industries, the main products are oil drilling rig, workover rig, drifting machine, trailermounted pumping unit winch (The main drum is used LBS grooved drum) and oil equipment accessories
