|Main Port:||Tianjin China||Power Source:||Electric|
|Drum Type:||Smooth Drum With LBS Sleeves||Sling Type:||Wire Rope|
|Application:||Oil, Marine And Geological Exploration||Product Color:||According To Customer Demand|
windlass anchor winch,
hydraulic towing winch
Brief view :
Product name: windlass winch
Durm type :smooth
Application:Oil, Marine And Geological Exploration
Function:pulling,pushing ,lifting ,hoisting ,fixed
Parts of model as follow:can design as customer
|Name||Shipyard Windlass Winch|
|Maximum Reel Weight:||Approx 65Ton|
|Reel speed:||Approx 1-6 rpm|
|Maximum Reel Width:||2.27m|
|Minimum Reel Windth:||1.17m|
|Maximum Reel Diameter:||3.0m (Flange Diameter)|
|Overall Dimensions of machine:||L4.68m x W2.3m x H3.2m|
|Pedestal Dimensions:||L4.83m x W2.5m|
|Tension (back force) on cable:||Approx 100KN|
|Tension (back force) on cable at 1st layer:||
The split-sleeve consists of a pair of outer shells that are bolted or welded onto the smooth drum of the windlass winch.
Shipyard Windlass Winch
1. Single or Multi-drum Type
4. Certificate Approval: ABS BV CCS DNV GL LR KR NK RINA RS etc.
5. With drag brake system
6. Configuration: horizontal arrangement
7. Rope speed: complying with ISO requirements
1. Top quality with competitive price.
2. Compact structure and reasonable design
3. Safe and reliable function.
4. Highly efficient, constant operating torque motor.
5. Smooth running over the entire speed range.
6. Reliable operation with little noise.
1. One Year Quality Assurance
2. Free Components for replacement within warranty period
3. Professional solution provider
4. Free techinical support at anytime
5. Marine winch,electric anchor winch, hand winch ,hydraulic winches ,windlass,capstan and outfitting can be designed
